• General

• Storage TemperatureStorage Temperature: -40 °C ~ 70 °C
• Working TemperatureOperating Temperature: 0 °C ~ 40 °C
• Working HumidityOperating Humidity: 10% – 90% RH non-condensing
• Storage HumidityStorage Humidity: 5% – 90% RH non-condensing
• Power Input100~240 V AC，50/60 Hz
• Power Consumption≤150w

Performance

• Switching Capacity7.2 Gbps
• Store-and-forwardSupported
• MAC Address Table4 k
• MAC Address LearningAuto-learning/ Auto-aging

PoE

• Working ModePriority, Standard, Isolate, Extend
• PoE StandardIEEE 802.3af, IEEE802.3at
• PoE Powering ModeSupports 8-pin power supply
• PoE Port1-16
• Maximum Total Output135 W
• Maximum Port Output30 W

Port

• High-priority PortPort 1 – 8
• 1000 Mbps SFP1 independent
• 10/100/1000 Mbps RJ451
• 10/100 Mbps RJ4516

Standard

• Network StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.3z

• Network
• Transmission SpeedEthernet: 10 Mbps (Half Duplex) / 20 Mbps (Full Duplex),Fast Ethernet: 100 Mbps (Half Duplex) / 200 Mbps (Full Duplex),Gigabit Ethernet: 2000 Mbps (Full Duplex)
• Transmission MediumEthernet: Cat 3 or better UTP/STP,Fast Ethernet: Cat 5 or better UTP/STP,Gigabit Ethernet: Cat 5 or better UTP/STP,1000 Base-SX: MMF (Multimode optical fiber),1000 Base-LX: MMF (Multimode optical fiber) or SMF (Single Mode Fiber)
• Lightning-proof Ranking4 kV

• PoE Powering ModeSupports 8-pin power supply
• PoE Port1-16
