• Image Sensor: 1/3″ Progressive Scan CMOS
• Max. Resolution: 2560 × 1440
• Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment: Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°

• LensHikvision Type : Fixed focal lens, 2.8  optional
• Focal Length & FOV : 2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
• Lens Mount : M12
• Iris Type  : Fixed
• Aperture: F1.6
• DORI :DORI 2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m

• Supplement Light Type: IR,White Light
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream :50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
• Video Compression : Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate: 32 Kbps to 8 Mbps
• H.264 Type

• Baseline Profile,Main Profile,High Profile
• H.265 Type: Main Profile
• Bit Rate Control: CBR,VBR
• Region of Interest (ROI): 1 fixed region for main stream

• Audio Type: Mono sound
• Environment Noise Filtering: Yes
• Audio Sampling Rate: 8 kHz/16 kHz
• Audio Compression
• G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC

• Audio Bit Rate : 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

• Security
• Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)

• Simultaneous Live View
• Up to 6 channels

• API
• Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK

• Protocols
• TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP

• User/Host
• Up to 32 users 3 user levels: administrator, operator, and user

• Client
• iVMS-4200,Hik-Connect

• Web Browser
• Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+

• Ethernet Interface
• 1 RJ45 10 M/100 M self-adaptive Ethernet port

• On-Board Storage: -F: Built-in memory card slot, support : icroSD/microSDHC/microSDXC card, up to 512 GB
• Built-in Microphone: Yes

• Reset Key: -F: Yes

• Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Linkage: Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture

• Power: 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W
• Material: Metal & Plastic

• English, Ukrainian

• General Function
• Heartbeat,anti-banding,mirror,password protection,password reset via email
