• Image Sensor 5 MP CMOS
• Max. Resolution2560 (H) × 1944 (V)
• Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Day & NightIR Cut Filter
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 85°, vertical FOV: 63°, diagonal FOV:110°

  3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105°

  6 mm, horizontal FOV: 57°, vertical FOV: 43°, diagonal FOV:72°

• Lens MountM12

Illuminator

• Supplement Light TypeIR
• Supplement Light RangeUp to 40 m
• Smart Supplement LightYes


• Image Parameters SwitchSTD/HIGH-SAT
• Image Settings

  Brightness,

  Mirror,

  Sharpness,

  Smart IR

• Frame Rate

  TVI: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps

  AHD: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps

  CVI: 4 MP @ 30 fps, 4 MP @ 25 fps

  CVBS: PAL/NTSC

• Day/Night ModeAuto/Color/BW (Black and White)
• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementDWDR;BLC;HLC;Global
• Noise Reduction2D DNR
• White Balance

  Auto,

  Manual

• AGCYes

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS
• Built-In MicrophoneYes

General

• MaterialFront cover: Metal, Main body: Plastic
• Dimension78.9 mm × 75.4 mm × 216.6 mm (3.10″ × 2.97″ × 8.53″)
• Approx. 338 g (0.75 lb.)
• Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish
• Power Supply12 VDC ± 25%
• ConsumptionMax. 4.5 W

Approval

• ProtectionIP67
